ORBCOMM ST 9100 - 1.1 Messaging System Overview

ST 9100 - INSTALLATION GUIDE
Figure 1: Remove SIM Card Door
3. Push and release any existing SIM card (Figure 2) to remove it from the SIM holder.
Figure 2: Remove any Existing SIM Card
4. Insert the SIM card, circuit up and the notch facing away from you and to the left (Figure 3).
Figure 3: Sample SIM Card Orientation
T414, Version 0.04 BETA © ORBCOMM
®
Proprietary
11
