ST 9100 - INSTALLATION GUIDE

APPENDIXH FIELD INSTALLABLE CONNECTOR

Below are the details for the ST 9100 Field Installable Connector (p/n ST101096).

Figure 22: ST 9100 Field Installable Connector

Figure 23: Connector Front View

Table 3: ST 9100 Field Installable Connector Details

Manufacturer Chogori

Waterproof IP67

Compliance CE RoHS

Connector Pin Assignment Refer to PIN # and Function columns in Table 2

Proprietary
