TECHNICAL MANUAL BLUE PAPER RISE · 20214 | ORBEA ORBEA | 5
EN
06 USE OF RISE 20
Turning Rise On/Off
Checking the battery level
Charging the batteries
Changing the assist mode
System errors
07 ORBEA RS TOOLBOX. RISE DATA DISPLAY ON COMPATIBLE
GARMIN UNITS 25
Install and unlock orbea rs toolbox on Garmin devices. Garmin connect app
Enabling Orbea RS Toolbox in your device
Using Orbea RS Toolbox
Activitiy data recording of Rise in Garmin Connect
08 SHIMANO ETUBE PROJECT. CUSTOMIZATION OF THE EP8 RS SYSTEM 34
System errors
09 GEOMETRY AND SIZING 36
Maximum and minimum saddle height with dropper seatposts
10 TECHNICAL SPECIFICATIONS 40
6GEJPKECNURGEKƂECVKQPU4KUG
6GEJPKECNURGEKƂECVKQPU5JKOCPQEP8 RS
11 ASSEMBLY AND SPARES 45
Headset
Headtube dimensions
*GCFUGVURGEKƂECVKQPU
Headset spare parts and assembly
Axles and derailleur hanger
Swingarm main pivot
Linkage
Linkage exploded view and spares
Linkage assembly
Shock assembly
Frame hardware and protectors
Chainguide
Rear derailleur and brake cable routing
Shimano EP8 components cable routing and connection
Shimano EW-EN100 junction assemblies (without display)
Differences between assemblies with Shimano EW-EN100 junction and with Shimano
SC-EM800 display
Connecting Rise to Shimano Etube professional. Information for dealers
Orbea RS components cable routing and connection
EP8 RS motor installation
RS internal battery
+PVGTPCNDCVVGT[ƂZKPIJCTFYCTGCPFGZRNQFGFXKGY
Internal battery removal. Information for Orbea dealers
RS Range Extender
Range Extender assembly
Connecting the Range Extender to Rise
Operation of the Range Extender
Battery level
Range Extender spares
12 RELEVANT INFORMATION ABOUT THE RS BATTERIES 72
13 SUSPENSION 77
Fox forks settings
Fox shocks settings
14 DECLARATION OF CONFORMITY 82
15 ADDITIONAL INFORMATION 83
