SAW CHAIN
SAW CHAIN
CHIPPER
Toe
TOOLS FOR FILING
PART N°. DESCRIPTION
70502 7/32" (5.5mm) Round File
13252 7/32" (5.5mm) Assembled File Guide
107488 .030" (0.64mm) Depth-gauge Tool
12211 Depth-gauge File (flat)
90406 Sharpening kit
FILING
➍ TOP-PLATE FILING
ANGLE:
Kickback
Reducing
Features
End View Use
Chains on this page are intended for use with saws 4.0 cu. in.
displacement (65cc) and larger, and with bars 20 in. (50cm) and
longer.
➊ DEPTH-GAUGE
SETTING:
➋ TOP-PLATE CUTTING ANGLE:
➌ SIDE-PLATE
ANGLE:
➎ FILE-GUIDE
ANGLE
CHAIN TYPE GAUGE
59AC .063" (1.6mm)
59CP .063" (1.6mm)
MICRO-BIT
®
.404"
