Alarms
−32−
8.2 Warnings
The warning types and records can be displayed on the monitor mode.
When a warning generates, the WNG output is turned ON. The WNG output is not assigned to the output terminal at the
time of shipment. Refer to "Description of I/O signals that can be assigned" on p.29.
The warning records will be cleared by turning o the control DC power supply.
Warning list
Warning
code
Warning
type
Motor
movement
Generation condition Remedial action
Motor lock
Continue to
operate
The motor output shaft was locked for one
second or more.
Check the load condition.
Operation
error
Stop
When the input terminal is ON, the FWD
input or REV input was assigned using the
"input function selection" parameter.
When assigning the FWD input
or REV input, check that the input
terminal to be assigned is being
OFF.
When moved from the test mode to any
of other modes after JOG operation was
executed, the FWD input or REV input was
being ON.
Turn both the FWD input and REV
input OFF.
To Next Page
