Oriental motor DSCD90EC - 11 Accessories (Sold Separately)

Accessories (sold separately)
−35−
11 Accessories (sold separately)

Connection cable
These cables are used to extend the wiring distance between the speed controller and motor. The connection cable can
be connected up to 3 pieces.
Flexible connection cables are also available.
Maximum extension distance between the motor and speed controller: 10.5 m (34.4 ft.) [including 0.5 m (1.6 ft.) of the
motor cable]
Speed
controller
Up to 10 m (32.8 ft.) can be extended
Up to 3 pieces can be connected
Motor
0.5 m
(1.6 ft.)

Connection cable

Flexible connection cable
Length Model Length Model
1 m (3.3 ft.)
CC01SC
1 m (3.3 ft.)
CC01SCR
2 m (6.6 ft.)
CC02SC
2 m (6.6 ft.)
CC02SCR
3 m (9.8 ft.)
CC03SC
3 m (9.8 ft.)
CC03SCR
5 m (16.4 ft.)
CC05SC
5 m (16.4 ft.)
CC05SCR
10 m (32.8 ft.)
CC10SC
10 m (32.8 ft.)
CC10SCR

General purpose cables for I/O signals
These cables are convenient to connect I/O signals of the speed controller.
Cables up to 2 m (6.6 ft.) are provided.
Length
Model
16 cores 12 cores
1 m (3.3 ft.)
CC16D010B-1 CC12D010B-1
2 m (6.6 ft.)
CC16D020B-1 CC12D020B-1

External potentiometer
This potentiometer is used to set and adjust the motor rotation speed remotely.
Model:
PAVR2-20K
Couplings and mounting brackets are provided as accessories (sold separately). Check on the Oriental Motor
Website for the product specications.
