Orion FLEX RTD User Manual

Orion Machine Manual
Revision 3.0 Flex Stretchwrapper
15 February 2016 System Operation
Page 3-15
Carriage Jog Screen
This is the Carriage Jog Screen. You can set the Carriage Up and Down Speeds, as well as
jog the carriage up or down.
Figure 3 - 10
The Carriage Jog
Screen
Table 3-9. The Carriage Jog Screen Button Descriptions
STATE 1 DESCRIPTION
CARRIAGE UP SPEED %
Press this button to modify the Carriage Up Speed, in terms of percentage. Min -
5% Max - 100%
CARRIAGE DOWN
SPEED %
Press this button to modify the Carriage Down Speed, in terms of percentage. Min -
5% Max - 100%
Press this button to jog the carriage upwards. The carriage move slowly upwards
until the operator releases the jog button.
Press this button to jog the carriage downwards. The carriage move slowly down-
wards until the operator releases the jog button.
