Orion ODC-10000 User Manual

- 24 -
ORION PDP
- 25 -
Innitely Expandable
Setting and operation of MSCS software5.

InserttheInstallationCD.y
Youcanseefollowinginstallationstartscreen.y
Selectproperversionforyourproductandstartinstallationy
y ®®󱱪
MSCSInstallationstartscreen.

1. Data for Picture control, Manual Tracking and so forth can be read by
clicking the right button of your mouse on the desired MLCD set from
MSCS.
Please do not use above function together with the other functions.
2. When you off AC power, execute power off by MSCS first and disconnect
AC power to save your configuration.


MSCSisanapplicationprogramneededtocontrolMLCD.y
WhenyouexecuteMSCS(v5.1)foryourproductattheinstallationscreen,itwillcreateay
newfolderat C:/ProgramFile/MSCS(v5.1) andanicononyourcomputerscreen.
BydoubleclickingtheMSCS(vy 5.1)icon,theinitialscreenimageofMSCS(v5.1)
willbedisplayedasshowninthepicture.
MainImageofMSCS(MultiScreenControlsystem)
MLCD

Orion ODC-10000 Specifications

General

Brand	Orion
Model	ODC-10000
Category	Monitor
Language	English
