- 30 -

ORION PDP

- 31 -

Innitely Expandable



Input the numbers of X and Y

X is for the number of row and Y is for column. -

X and Y can be selected within the range from 1 to 15. The maximum MLCD quantity of MSCS

control is 100 sets.

MLCD image of selected numbers of X and Y is displayed in the Screen configuration in one

second after setting the number.

ScreenConfigurationSetting

Select one of input sources from DVI, PC or Video

Execution of the configuration.

When you click "PLAY"button after selecting input source from Source select and the numbers of -

X and Y in MLCD Configuration, the configuration of MLCD is generated as shown in the figure

below.

※ 

Check the resolution of the input source. It is displayed at the upper right corner of the screen. -

Check the signal. If there is no input signal, "No signal" is displayed. -

DVI



WhenComPortissuccessfullyconnected,pop-upwindowfor"Newdesign/Lastdesign"y

appears.

New/LastDesignSet

Click"OpenNewDesign"topreparenewconfiguration.y

Click"OpenLastDesign"togotolastdesignbeforeclosing.y



WhentheconnectionissuccessfullycompletedaftersettingComPort,followingy

Messagedialogisdisplayed.Thedialogwindowwillbedisappearedin1second.



MLCD
