Pleasesecureminimumclearanceasshowninthepictureforadequateventilationandtechnicalservice.

Thesetcanbeinstalledasshownbelow.y
(Forfurtherinformation,refertotheoptional'MAINFRAMEInstallationandSetupGuide'.)
Pleasedonotinstallourproductatfollowinglocationstoprotecttheproductandy
preventpossiblemalfunction.
-Placesofvibrationorshock:LCDsetmayfallanddamaged
-NextorneartoSprinklersensors:Thesensorsmaydetectheatfromasetandsprinklercanbeactivated.
-Aroundhighvoltagepowerlines:Noisefromthepowerlinemayaffectscreenimages
-Aroundheatingapparatus:LCDsetmaybeoverheatedanddamaged.
GuidePin
Hanger
HangerBolt
LCD
MAIN
FRAME
20cm
20cm
20cm
20cm

Thesetcanbeinstalledonthewallasshownbelow.y
(Forfurtherinformation,refertotheoptional'MAINFRAMEInstallationandSetupGuide'.)

Pleasesecureminimumclearanceasshowninthepictureforadequateventilationandtechnicalservice.
Pleasecheckthey stabilityofwall.
Ifthewallisnotstrongenough,reinforcethewallbeforeinstallation.
Pleaseconnectallthecablestoproperportsinasetbeforeinstallation.y
Hanger
HangerBolt
LCD
MAIN
FRAME
GuidePin
WALLBRACKET
20cm
20cm
20cm20cm
