Orion ODC-10000 User Manual


-SinceMLCDpanelisverysensitiveforphysicalimpact,installationrequires
considerablecaution.
-Minimumclearance(20cm)mustbesecuredforsmoothventilation.(SeeP12~13)
Installationmustavoidairtightornearairtightplaces.Improperventilationcauses
malfunctionandshortensproductlifetimebyrapidinternaltemperaturerise.If
MLCDhastoinstalledattheimproperventilation,additionalventilationopenings
orfansmustbeprovidedtokeeptheinternaltemperaturebetween0~35℃.
-ForgroundofMLCDandapplicationdevices,itshouldbeconnectedasframe
ground.
-ConsideringMLCDMaxpowerconsumption,checkthemainelectricspecification.


-WhenyoudesigntheexteriordesignforMLCDsystem,considereasier
disassemblyforpossibleserviceoccasioninthefuture.
-TheslidingUniversalUnitofORIONPDPisrecommendedforeasierservice.
-IfservicepeoplecanstepintothebacksideofMLCDsystem,itcangreatly
reducetimeandeffortforservice.
-Incaseofhigherlocations,considertheinstallationlocationandexteriordesign
foreasierservice.
※Cautions for consisting MLCD System

-Theimagequalitymayvarydependonthequalityofsignalandcablecondition.
INPUT SOURCE Resolution Connection Remark
DVI 1600x1200x60Hz 6sets 
PC 1600x1200x60Hz 3sets
Video NTSC,PAL,SECAM 6sets
RS-232C 30sets ORIONCableOnly
-IfyouneedtousemoreMLCDsetsthanindicatedinthetable,usingaDVI
distributorishighlyrecommended.


-Ifyouwanttouseautomaticpoweron/offfunctionthatmakeMLCDturnedon/
offbyconnectingmainpower,allowatleast20secondsofStand-bytimebefore
MLCDisturnedon,whenyoumakecontrolprogram.
-IfRS-232Ccommunicationsignalorotherimagesignalisappliedto9ormore
setssimultaneously,communicationalerrormayoccur.(Poweron&Broadcast)

- 4 -
ORION PDP

- 5 -
Innitely Expandable

MLCD
