Orion ODC-10000 User Manual

- 38 -
ORION PDP
- 39 -
Innitely Expandable
Click "Stop" button to end "Slide Control" 6.
Save or Load the slide configuration 7.
Click "SAVE" button to save user added Slide configuration as "*.ssd" file. -
Click "LOAD" button to open saved "*.ssd" file. -
※Toviewthesavedscreenconfiguration,selectthelistfrom"ListBox."
※SavedscreenprotocolistransmittedtoMLCDbydoubleclickingthelist.
Whenyouload"SlideFile",previousslide
configurationandnewslideconfigurationmustbe
identical.
Iftheyaredifferent,thefilecannotbeloaded.So,
revisethenewslidefileconfigurationasprevious
configurationorsaveasnewfile.


RegistervaluesrelatedtodisplayofMLCDcanbechanged.y
TousePictureControl,gotoMSCSMenu→Control→PictureControlorpress"Ctrl+P"y
usingKeyboard.
Inordertocontroldisplayvalues,inputvaluesdirectlyin"EditBox"andpressEnterkey.y
Orclick-/+buttonusingmouse.
Click"Exit"buttonorpress"Ctrl+X"usingkeyboardtoclose"PictureControl"window.y

y :Changethecolortemperatureofthescreen
-Normal:Initialsetting.Properfornormalvideoimageview.
-Studio:LowColortemperature.Properforbroadcastingpurpose.
y :Therangeof"Brightness"youcanadjustis0to100.
y :Therangeof"Contrast"youcanadjustis0to100.
y :Therangeof"Sharpness"youcanadjustis0to28.
y :Userscanadjustcolorimpressionwithwhitescreenandsaveorloadthe
adjustedvalue.
- Save - Save User’s data file (*.pdt)
- Load - Load User’s data file (*.pdt)
MLCD

Orion ODC-10000 Specifications

General

Brand	Orion
Model	ODC-10000
Category	Monitor
Language	English
