SettheoutputresolutionofDVIConverter.y
Resolution frequency
640 x 480 60Hz / 85Hz
800 x 600 50Hz / 60Hz / 85Hz
853 x 480 50Hz / 60Hz
1024 x 768 60Hz / 85Hz
1280 x 1024 50Hz / 60Hz
1600 x 900 50Hz / 60Hz
1600 x 1200 50Hz / 60Hz
1706 x 960 60Hz
1920 x 1080p 50Hz / 60Hz
y :Settheoutputresolution.

TheDVIconverterinputandinputresolutionaredisplayedonthescreen.y

Setorchangethescreenratio(Horizontal:Vertical)y
y :Setthescreenratioas16:9widescreen.
y :Setthescreenratioas4:3
y :Expandthescreenimagetoremovetheblackpatternsatthetopand
bottomportionsofthescreen.
y :Expandthescreenwiththesubtitletothetopportion.(The
bottomportionremainswithblackpattern)

LockthefrontkeyofDVIConverternottoturnOnorOff.y

DisplaytheDVIConverterstatus(InputSource,InputResolution,OutputResolution,Aspecty
Ratio,PIPMode,TestPattern,KeyLock,FreeRun/Lock,FirmwareVersion,MSCSVersion
information)
