ControltheScreensize,sharpness,andpositionofDVIConverterwithPCinputmode.y
Incasey alignmentdoesn'tworkthrough"TrackingAuto"command,userscantunefinely
through"ManualTracking".
"ManualTracking"windowenablesuserstosetFrequency,Phase,LineStartandPixelStart.y
Detailadjustmentstepsareasfollows.y
1)Tune"Phase"untiltheverticallinesareclearlyadjusted..
2)Tune"LineStart"toadjustverticalalignment."PixelStart"forhorizontalalignment.
3)Adjust"Frequency"ifalignmentisstillwrong.
Ifyouadjust"Frequency",repeatstep1)and2)tofitalignment.
Adjustablerangeisasfollows
y :Therangeof"Frequency"youcanadjustis-50to50
y :Therangeof"Phase"youcanadjustis0to63
y :Therangeof"Linestart"youcanadjustis-23to10
y :Therangeof"Pixelstart"youcanadjustis-50to40
y :AutomaticalignmentforDVIConverterscreens.
y :AutomaticcolorcontrolforDVIConverterscreen.

AvarietyofimagescanbedisplayedwiththePIPfunctionofDVIconverter.Toactivatey
PIP,click"PIP"intheMode.Thepositionofsub-picturecanbecontrolledbyclicking-/+
buttonsincreaseordecreasethenumberordirectlytypeinthenumbersatEditbox.
Variousinputsourcescanbeused.Tosetthesub-input,clickthesub-inputcomboboxy
andselectsub-input.
Mainscreenandsub-screencanbeswappedwiththePIPSwapfunction.Press"Set"y
buttonattherightsideof"PIPSwap."Ifyouwanttoreturntopreviousscreen,press
"Normal"buttonattherightsideof"PIPSwap."
y :Normalmode-NormalscreenwithoutPIP(PIPOff)
PIPmode-Sub-screenisdisplayedatthelowerrightcornerofthescreen.(PIPOn)
y :Horizontal-AdjustthehorizontallocationofPIP.Adjustablerange0~100
Vertical-AdjusttheverticallocationofPIP.Adjustablerange0~100
y :SettheinputforPIP.OneofDVI,HDMI,HDSDI,PC,DTV,S-VIDEO,andVIDEO
canbeselectedforsub-input.
According to the main input, the sub-input can be restricted. If the main input is a digital input ※
such as DVI, HDMI or HD-SDI, the sub-input should be an analog input such as PC, DTV,
S-VIDEO or Video. If the main input is an analog input the sub-input should be a digital input.
y :OFF-ReturntopreviouslocationsofswappedMainSourceInputscreenand
SubSourceInputscreen.
ON-ExchangethelocationsofMainSourceInputscreenandSubSourceInput
screen.
