ww.teamorion.com 15
3. “Forward/Reverse” this mode is meant for Rock Crawler
use. In this mode there is no brake, the car can go from
forward to reverse immediately without any pause. Do
not use this mode with other car types as it can overload
and/or damage the ESC.
Running modes 4-5-6 have the same functions as 1-2-3 but
all timing functions of the software are disabled. Setting
your ESC to running mode 4-5-6 means that the ESC is
running in “Blinky” mode.
2. Drag Brake Force
Sets the amount of brake automatically applied when the
throttle is returned to the neutral position. This simulates
the engine breaking eect of a real car.
3. Low Voltage Cut-o
This function helps to prevent battery over-discharge. The
ESC continuously monitors the battery’s voltage. If the
voltage becomes lower than the threshold for 2 seconds,
the output power is shut o and the red LED ashes twice
repeatedly. The cuto threshold calculation is based on LiPo
individual cell voltage. For NiMH batteries, if the voltage
battery pack is higher than 9.0V, it will be considered as
a 3 cell LiPo battery pack; if it is lower than 9.0V, it will be
considered as a 2 cell LiPo battery pack. Using the optional
Digital Program box you can adjust custom values for the
cuto threshold. Unlike the preset values, custom cuto
values are for the total battery voltage not individual cell
voltage.
