PARAMÈTRES DU VARIATEUR ET RÉGLAGES PAR DÉFAUT
Paramètre
(indiqué par la LED
verte )
Réglage (indiqué par la LED rouge )
1 2 3 4 5 6 7 8 9
Paramètres standard (modiables avec le bouton de réglage)
1 Running
Mode
Forward
with
Brake
Forward/
Reverse
with
Brake
Foward/
Reverse
(For
Rock
Crawler)
Zero
Timing
Forward
with
Brake
Zero
Timing
Forward/
Reverse
with
Brake
Zero
Timing
Forward/
Reverse
(For Rock
Crawler)
2 Drag Brake
Force 0% 5% 10% 15% 20% 25% 30% 100%
User set
in 1%
steps
3 Low Voltage
Cut-O
Threshold
No
Protection
2.6V/Cell
2.8V/
Cell
3.0V/
Cell
3.2V/Cell 3.4V/Cell
User set
in 0.1V
steps
4 Start Mode
(Punch)
Level 1 Level 2 Level 3 Level 4 Level 5 Level 6 Level 7
Level
8
Level 9
5 Max Brake
Force
12.50% 25% 37.50% 50% 62.50% 75% 87.50% 100%
6 Max Reverse
Force
25% 50% 75% 100%
7 Initial Brake
Force
Drag
Brake
Force
0% 20% 40%
8 Débattement
neutre
6%
(Narrow)
9%
(Normal)
12%
(Wide)
9 Protection
surchaue
Enable Disable
Paramètres avancés (modiables uniquement avec le boîtier de programmation)
Micrologiciel « Modié »
(par défaut)
Micrologiciel « Stock »
(via mise à jour micrologiciel)
10 Boost Timing 0° to 16° in 1° steps, default 0° 0° to 64° in 1° steps, default 33°
11 Boost Start
RPM
not available
1000RPM to 15000RPM in 1000RPM steps,
default 4000PRM
12 Boost Timing
Acceleration
not available
50RPM/deg to 750RPM/deg in 50RPM steps,
default 350RPM/deg
13 Turbo Timing 0° to 20° in 1° steps, default 10° 0° to 40° in 1° steps, default 12°
14 Turbo Slope
Rate (/0.1s)
3° 6° 12° 18° 24° Fastest 3° 6° 12° 18° 24° Fastest
15 Turbo Delay
o 0.1s 0.2s 0.3s 0.4s 0.5s 0.6s 0.7s 0.8s o 0.1s 0.2s 0.3s 0.4s 0.5s 0.6s 0.7s 0.8s
