Orion Vortex R10 pro User Manual

8 Copyright Team Orion © 2014
PROGRAMMING YOUR ESC
OR
2 2
3
3 3
1
7
4
6
5
Connect the battery
Enter Programming Mode
S
elect the parameter you wish to modify
Reset to factory default settings
Press the
SET button
for 1s
Press the
SET button
for 5s
Press the SET button
1 time to select the
1st parameter...
...press the SET button
2 times to select the
2nd parameter etc.
Switch ON
Switch OFF
ESC to complete
the procedure
LED
blinks
LED blinks 1 time
LED blinks
1 time
LED blinks 2 times
Press the SET button
for 3s to modify
the setting of the
parameter
Press the SET button
for 3s to save the
new setting
Use the SET button
to change the setting
of the parameter.
Press 1 time
LED blinks
2 times
Press 2 times etc.
