Orion Vortex R10 pro User Manual

52 Copyright Team Orion © 2014
RAPPORTS CONSEILLÉS
Moteur KV
Rapport nal
1/10 Touring
Rapport nal
1/10 Buggy
Variateur
ORI65102 ORI65128
3.5T 9100 9.0 - 11.0 - √ √
4.5T 7300 8.4 - 10.0 - √ √
5.5T 6000 8.0 - 9.4 9.5 - 11.0 √ √
6.5T 5200 7.4 - 8.4 9.0 - 11.0 √ √
8.5T 4000 6.0 - 7.0 8.0 - 9.6 √ √
10.5T 3300 5.0 - 6.0 7.0 - 8.5 √ √
11.5T 3000 4.5 - 5.5 6.5 - 8.0 √ √
13.5T 2500 4.0 - 5.0 6.5 - 7.5 √ √
17.5T 1900 3.8 - 4.5 5.5 - 7.0 √ √
21.5T 1600 3.5 - 4.0 5.0 - 5.5 √ √
RÉGLAGES DE BASE POUR MOTEURS STOCK
Voiture Moteur Rapport
Final
10. Boost
Timing
11. Boost
Start
RPM
12. Timing
Acceleration
13.
Turbo
Timing
14.
Turbo
Slope
Rate
15. Turbo
Delay
1/10 On-Road
11.5T 6.0-7.0 34°-42° 4000 300-450 16°-26° 18°/0.1s 0.4s
13.5T 5.0-7.0 34°-54° 3000 200-300 20°-30° 18°/0.1s 0.4s
17.5T 5.0-7.0 34°-55° 3000 150-300 20°-30° 18°/0.1s 0.2s
1/10 O-Road
11.5T 7.5-9.5 12° 6000 400-500 4° 6°/0.1s O
13.5T 7.0-9.0 16° 5000 200-350 8° 6°/0.1s O
17.5T 7.0-8.5 20° 3000 200-350 12° 6°/0.1s O
