15
UM0972080 A 03
Figure 21
Figure 20
Figure 25
Figure 22
Figure 23
Figure 24
4. Service menu
4.2. Camera tags
See Figure 20. In this menu, names can be given to the camera inputs.
See Figure 21.
The number of inputs depends on the video switch type that is set (see
section 4.3.8. on page 18).
4.3. System settings (see Figure 22)
4.3.1. Language
See Figure 23. This option opens the language selection menu. The
selected language will be used for all OSD menus. The OSD menu is
available in English, Dutch, German, French, Chech, Hungarian, Italian,
Polish, Portuguese, Spanish, Turkish, Swedish, Finnish, Danish and
Norwegian.
4.3.2. On Screen Display (OSD)
This option opens the OSD settings menu. See Figures 24 + 25. The
following can be set in this menu:
OSD time-out
Sets the time (in seconds) that the OSD (camera number/name, top
left) appears on the monitor. Select 'O' to disable this and 'On' to
have this permanently enabled.
Position of the OSD
This option is used to set the horizontal position of the OSD menu
text.
Info transparency
Changes the transparency of the camera tag, etc.
Menu transparency
Changes the transparency of the system menu.
Disclaimer transparency
Changes the transparency of the disclaimer when starting up.
OSD menu help
This function enables or disables the automatic text messages of the
OSD help menus. If enabled, help messages automatically appear in
all menus after 10 seconds of inactivity.
