Ormazabal cpg.0 ENA Series User Manual

IG-273-EN version 03; 05/08/2020
5
General instructions
cpg.0 ENA range
General description
PROVISIONAL
1. General description
The cpg.0 switchgear range is made up of a series of cubicles,
with complete insulation in SF
6
, for primary distribution in
medium-voltage networks up to 36 kV.
1.1. Models
Model Function
cpg.0-v Circuit breaker
cpg.0-l Switch-disconnector
cpg.0-c Bus section circuit breaker
cpg.0-pt Busbar earthing switch
cpg.0-rb Busbar riser
1.2. Standards applied
Standard Description
IEC 62271-1 Common specications for high-voltage switchgear standards
IEC 62271-200 Alternating current metal-enclosed switchgear and controlgear for rated voltages above 1 kV and up to and
including 52 kV
IEC 62271-100 Alternating current circuit-breakers
IEC 62271-102 Alternating current disconnectors and earthing switches
Technical Specication
41-36 Issue 3 2017
Switchgear for service up to 36kV (cable and overhead conductor connected)

Ormazabal cpg.0 ENA Series Specifications

General

Brand	Ormazabal
Model	cpg.0 ENA Series
Category	Industrial Electrical
Language	English
