IG-267-EN versión 01; 07/04/2017
105
General Instructions
ekor.rpa
Communications
Clock (0 x 03XX)
Address Field Description Size Read/write
0 x 0300 YEAR Year (from 2000 to 2059) 16 bits Read/write
0 x 0301 MONTH DAY Month (from 1 to 12) DAY (FROM 1st to 31st) 16 bits Read/write
0 x 0302 TIME MIN Time (FROM 0 to 23) MINUTE (from 0 to 59) 16 bits Read/write
0 x 0303 00 SEC 0 SECOND (from 0 to 59) 16 bits Read/write
Table 12.7. Clock
Password (0 x 05XX)
Address Field Description Size Read/write
0 x 0500 User Key.
Key to access settings with user privileges
(From 0 to 9999)
16 bits Write-only
Table 12.8. Password
Commands and outputs (0 x 06XX)
Address Field Description Size Read/write
0 x 0600 cmb0-cmb15
Write: From cmb0 (LSB) to cmb15 (MSB)
Read: From SAL1 (LSB) to SAL7 and from cmb7 to cmb15 (MSB)
16 bits Read/write
0 x 0601 cmb16-cmb31 Read and write: From cmb16 (LSB) to cmb31 (MSB) 16 bits Read/write
0 x 0602 cmb32-cmb47 Read and write: From cmb32 (LSB) to cmb47 (MSB) 16 bits Read/write
0 x 0603 cmb48-cmb63 Read and write: From cmb48 (LSB) to cmb63 (MSB) 16 bits Read/write
Table 12.9. Command and outputs
Meterings and statuses (0 x 07XX)
Address Field Description Size Read/write
0 x 0700 VA A Phase voltage (Volts) 32 bits Read
0 x 0702 VB B Phase voltage (Volts) 32 bits Read
0 x 0704 VC C Phase voltage (Volts) 32 bits Read
0 x 0706 VN Neutral voltage (Volts) 32 bits Read
0 x 0708 IA A phase current (Hundredths of an ampere) 32 bits Read
0 x 070A IB B phase current (Hundredths of an ampere) 32 bits Read
0 x 070C IC C phase current (Hundredths of an ampere) 32 bits Read
0 x 070E INS Sensitive neutral current (Hundredths of an ampere) 32 bits Read
0 x 0710 emb0-emb15 MODBUS statuses of the 0 (LSB)–15 (MSB) 16 bits Read
0 x 0711 emb16-emb31 MODBUS statuses of the 16 (LSB)–31 (MSB) 16 bits Read
0 x 0712 emb32-emb47 MODBUS statuses of the 32 (LSB)–47 (MSB) 16 bits Read
0 x 0713 emb48-emb63 MODBUS statuses of the 48 (LSB)–63 (MSB) 16 bits Read
0 x 0714 emb64-emb79 MODBUS statuses of the 64 (LSB)–79 (MSB) 16 bits Read
0 x 0715 emb80-emb95 MODBUS statuses of the 80 (LSB)–95 (MSB) 16 bits Read
0 x 0716 emb96-emb111 MODBUS statuses of the 96 (LSB)–111 (MSB) 16 bits Read
0 x 0717 emb112-emb127 MODBUS statuses of the 112 (LSB)–127 (MSB) 16 bits Read
0 x 0718 PA Active power of phase A (Watts) 32 bits Read
0 x 071A PB Active power of phase B (Watts) 32 bits Read
0 x 071C PC Active power of phase C (Watts) 32 bits Read
0 x 071E PT Total active power (Watts) 32 bits Read
0 x 0720 QA Reactive power of phase A (VAr) 32 bits Read
0 x 0722 QB Reactive power of phase B (VAr) 32 bits Read
0 x 0724 QC Reactive power of phase C (VAr) 32 bits Read
0 x 0726 QT Total reactive power (VAr) 32 bits Read
0 x 0730 Set at 0 x FF Set at 0 x FF 16 bits Read
0 x 0731 ANG(VA/VA) VA/VA angle [always 0] 16 bits Read
0 x 0732 ANG(VB/VA) VB/VA angle [from 0 (0.0°) to 3599 (359.9°)] 16 bits Read
Continued on next page
