IG-267-EN versión 01; 07/04/2017
106
Communications General Instructions
ekor.rpa
Continuation
Address Field Description Size Read/write
0 x 0733 ANG(VC/VA) VC/VA angle [from 0 (0.0°) to 3599 (359.9°)] 16 bits Read
0 x 0734 ANG(VN/VA) VN/VA angle [from 0 (0.0°) to 3599 (359.9°)] 16 bits Read
0 x 0735 ANG(IA/VA) IA/VA angle [from 0 (0.0°) to 3599 (359.9°)] 16 bits Read
0 x 0736 ANG(IB/VA) IB/VA angle [from 0 (0.0°) to 3599 (359.9°)] 16 bits Read
0 x 0737 ANG(IC/VA) IC/VA angle [from 0 (0.0°) to 3599 (359.9°)] 16 bits Read
0 x 0738 ANG(INS/VA) INS/VA angle [from 0 (0.0°) to 3599 (359.9°)] 16 bits Read
0 x 0739 ANG(INC/VA) INC/VA angle [from 0 (0.0°) to 3599 (359.9°)] 16 bits Read
0 x 0740 INC Calculated neutral current (Hundredths of an ampere) 32 bits Read
0 x 0750 IA
(1)
Circuit-Breaker Direct sequence (hundredths of an ampere) 32 bits Read
0 x 0752 IA
(2)
Circuit-breaker inverse sequence (hundredths of an ampere) 32 bits Read
0 x 0754 IA
(0)
Circuit-breaker zero-sequence (hundredths of an ampere) 32 bits Read
0 x 0756 ANG(IA
(1)
/VA) IA(1)/VA angle [from 0 (0.0°) to 3599 (359.9°)] 16 bits Read
0 x 0757 ANG(IA
(2)
/VA) IA(2)/VA angle [from 0 (0.0°) to 3599 (359.9°)] 16 bits Read
0 x 0758 ANG(IA
(0)
/VA) IA(0)/VA angle [from 0 (0.0°) to 3599 (359.9°)] 16 bits Read
0 x 0770 UAB A-B Compound voltage (Volts) 32 bits Read
0 x 0772 UBC B-C Compound voltage (Volts) 32 bits Read
0 x 0774 UCA C-A Compound voltage (Volts) 32 bits Read
0 x 0776 ANG(UAB/VA) UAB/VA angle [from 0 (0.0°) to 3599 (359.9°)] 16 bits Read
0 x 0777 ANG(UBC/VA) UBC/VA angle [from 0 (0.0°) to 3599 (359.9°)] 16 bits Read
0 x 0778 ANG(UCA/VA) UCA/VA angle [from 0 (0.0°) to 3599 (359.9°)] 16 bits Read
0 x 0780 SA Apparent power of phase A (VAs) 32 bits Read
0 x 0782 SB Apparent power of phase B (VAs) 32 bits Read
0 x 0784 SC Apparent power of phase C (VAs) 32 bits Read
0 x 0786 ST Total apparent power (VAs) 32 bits Read
0 x 0788 FPA F.P. phase A [from 0000 (0.000) to 1000 (1,000)] 16 bits Read
0 x 0789 FPB F.P. phase B [from 0000 (0.000) to 1000 (1,000)] 16 bits Read
0 x 078A FPC F.P. phase C [from 0000 (0.000) to 1000 (1,000)] 16 bits Read
0 x 078B FPT F.P. total [from 0000 (0.000) to 1000 (1.000)] 16 bits Read
Table 12.10. Meterings and statuses
Meters (0 x 0AXX)
Energy (from 0 x 0A00 to 0 x 0A1F)
Three-phase
Address
(HEX)
Field Description Size Read/write
0 x 0A00 ET+ Active energy imported (in kWh) total. 32 bits Read
0 x 0A02 ET- Active energy exported (in kWh) total 32 bits Read
0 x 0A04 QT1 Reactive energy Q1 (in kVArh) total 32 bits Read
0 x 0A06 QT2 Reactive energy Q2 (in kVArh) total 32 bits Read
0 x 0A08 QT3 Reactive energy Q3 (in kVArh) total 32 bits Read
0 x 0A0A QT4 Reactive energy Q4 (in kVArh) total 32 bits Read
Table 12.11. Three-phase
Single-phase
Address
(HEX)
Field Description Size Read/write
0 x 0A0C EA+ Active energy imported (in kWh) phase A 32 bits Read
0 x 0A0E EA- Active energy exported (in kWh) phase A 32 bits Read
0 x 0A10 QA1 Reactive energy Q1 (in kVArh) phase A 32 bits Read
0 x 0A12 QA2 Reactive energy Q2 (in kVArh) phase A 32 bits Read
0 x 0A14 QA3 Reactive energy Q3 (in kVArh) phase A 32 bits Read
0 x 0A16 QA4 Reactive energy Q4 (in kVArh) phase A 32 bits Read
Continued on next page
