1.3.6 10 MHz Output
Signal: 10 MHz sine wave
Signal Level: +13 dBm ±2dB into 50 Ω
Harmonics: ˗40 dBc minimum
Spurious: ˗70 dBc minimum TCXO
Connector: BNC female
Signature Control: This configurable feature removes the output signal whenever
a major alarm condition or loss of time synchronization condition is present. The out-
put will be restored once the fault condition is corrected.
Table 1-3:
10 MHz output — oscillator types and accuracies
Oscillator Type Accuracy
Low-phase noise Rubidium 1x10
-12
typical 24-hour average locked to GPS
1x10
-11
per day (5x10
-11
per month) typical aging unlocked
Rubidium 1x10
-12
typical 24-hour average locked to GPS
1x10
-11
per day (5x10
-11
per month) typical aging unlocked
Low-phase noise OCXO 1x10
-12
typical 24-hour average locked to GPS
2x10
-10
per day typical aging unlocked
OCXO 2x10
-12
typical 24-hour average locked to GPS
1x10
-9
per day typical aging unlocked
TCXO 1x10
-11
typical 24-hour average locked to GPS
1x10
-8
per day typical aging unlocked
1.3.7 Mechanical and Environmental Specifications
Dimensions:
Designed for EIA 19” rack mount:
Housing w/o connectors and brackets:
16.75” W x 1.72” H [1U] x 14.33” D actual
(425 mm W x 44 mm H x 364 mm D)
Weight:
6.0 lbs (2.72 kg)
1.3 Specifications
SecureSync Getting Started Guide Rev. 12.0 11
