The USB connector is reserved for future expansion.
The 1PPS BNC connector offers a once-per-second square-wave output signal.
The 10 MHz BNC connector provides a 10 MHz sine-wave output signal.
The optional ANTENNA connector is a type “N” connector for the GNSS input from
your GNSS antenna via a coax cable.
1.3 Specifications
The following specifications apply to the standard configuration of SecureSync. Inform-
ation on option card specifications can be found in the main user manual.
1.3.1 Input Power
AC power source:
100 to 240 V
AC
, 50/60 Hz, ±10 %, or
100 to 120 V
AC
, 400 Hz, ±10% via an IEC 60320 connector (power cord included)
DC input (option):
12-17 V
DC
-15%, +20%, or
21-60 V
DC
-15%, +20%, secure locking device
Maximum power draw:
TCXO/OCXO oscillator installed: 40 W normal (50 W start-up)
Rubidium (Rb) oscillator installed: 50 W normal (80 W start-up)
Low-Phase Noise (LPN) Rubidium oscillator installed: 52 W normal (85 W start-up)
Battery:
BR3032 lithium coin-cell (3V DC- 500mAh)
1.3.1.1 Fuses
Type: T 2A L 250V
Model:
Orolia recommends: LITTELFUSE 0213002.MXP
[Orolia part number: F010R-0002-000 E FUSE,2A,SB,IECSURGE,GLASS]
Number: 2 (two) per unit
8
SecureSync Getting Started Guide Rev. 12.0
1.3 Specifications
