Figure 2-1: SecureSync front panel
3.
Check the front panel status LED indicators:
The Power lamp should be solid green.
The Sync lamp will probably be red, since synchronization has not yet been
achieved.
The Fault lamp will be OFF, or solid orange, indicating a minor alarm, or solid
red, asserting a power-up frequency error alarm (until the disciplining state is
reached.)
2.9 Network Setup
There are three methods that can be used to communicate with your SecureSync in order
to set up an IPv4 address and configure inputs and outputs; the best method will depend
on your specific setup and connections.
The web user interface ("Web UI") is the most complete way to configure and
monitor the unit. The Web UI is available through the Ethernet port via a network
connection. Using the Web UIrequires a web browser.
The Command Line Interpreter ("CLI") is available through the RJ45 serial port
(front panel) or through an Ethernet connection. The CLI can be either a means to
configure the unit to allow access to the Web UI, or the principal means of com-
munication with your SecureSync. Using the CLI requires a terminal emulator pro-
gram.
The command helpcli provides a list of helpful commands (press q or ctrl c to exit)
as does the main user manual.
The front panel display menu also allows monitoring and settings adjustments.
Using the front panel display requires physical access to the unit.
Note: The default credentials for both the Web UI and the CLI are:
username: spadmin
password: admin123
24
SecureSync Getting Started Guide Rev. 12.0
