Specification
GigabitethernetRJ45jack(1000BASE-T).
VINBarrelJack. Usewitha5.5mmODx2.5mmIDbarrelplug.
Userreplaceable5Afuse. UseonlyLittlefuse #0891005.
VIN greenLED indicator,fuse-protected VIN header (J10)andGroundheader / jumper storage
(J14).
OnboardbuckpowersupplygeneratingVCC_3P3|5. VCC_3P3|5suppliestheonboardLEDsand
pullups,andisuseraccessibleviaheadersJ2&J7. HeaderJ5isusedtoselectthebuck’soutput
voltage: installajumperfor3.3V,leaveopenfor5V.WARNINGS:Maxallowableuserconsumption
is210mA.EnsurepowertotheInterfaceBoxisdisconnectedwhenchangingbuckoutputvoltage
viaJ5.
3.3kω pullups to VCC_3P3|5 and green LED indicators for SYNC_PULSE_IN and MULTIPUR-
POSE_IO.Installajumperontherespectiveheader(J9orJ8)toenablethepullup.
0.1” pitch, 4x2 pin header J7. GPS_TX (Pin 1) is only connected to connector J2; it is not con-
nectedtothesensor.
6-pinJSTSH/SRconnectorJ2. VCC_J2(Pin2)isconnectedtoVCC_3P3|5byinstallingajumper
onheaderJ6. GPS_TX(Pin6)isonlyconnectedtoheaderJ7;itisnotconnectedtothesensor.
Note: Thisinterfacebox is no longer available for purchase and is specified in this manualonly for
reference for existing users. This is optional for Rev 06 Sensors and above and is compatible with
Type3double-endedCablesonly.
InterfaceBox24V(LegacyType 1 and Type 2)
FormoreinformationonthispleaserefertoRev06orpriorHardwareUserManuals.
Figure 7.10: Sensor-Interfaceboxconnectivity
