OXE 200 HP - Fault Codes

59
FAULT CODES
NIRA Internal
fault code
J1939
SPN
J1939
FMI
Description
0 157 3 Fuel rail pressure sensor - Voltage above normal, or shorted to high source
1 157 4 Fuel rail pressure sensor - Voltage below normal, or shorted to low source
4 102 3 Manifold air pressure sensor - Voltage above normal, or shorted to high source
5 102 4 Manifold air pressure sensor - Voltage below normal, or shorted to low source
8 100 3 Engine oil pressure sensor - Voltage above normal, or shorted to high source
9 100 4 Engine oil pressure sensor - Voltage below normal, or shorted to low source
12 Air filter differentail pressure sensor - Voltage above normal, or shorted to high
source
13 Air filter differentail pressure sensor - Voltage below normal, or shorted to low
source
24 171 3 Ambient air temperature sensor - Voltage above normal, or shorted to high
source
25 171 4 Ambient air temperature sensor - Voltage below normal, or shorted to low
source
26 Trim angle sensor - Voltage above normal, or shorted to high source
27 Trim angle sensor - Voltage below normal, or shorted to low source
30 Hydraulic oil pressure - Voltage above normal, or shorted to high source
31 Hydraulic oil pressure - Voltage below normal, or shorted to low source
76 DG_FNO_ECU_VREF_AIN_HIGH
77 DG_FNO_ECU_VREF_AIN_LOW
78 Hydraulic oil temperature - Voltage above normal, or shorted to high source
79 Hydraulic oil temperature - Voltage below normal, or shorted to low source
92 105 3 Manifold air temperature sensor - Voltage above normal, or shorted to high
source
93 105 4 Manifold air temperature sensor - Voltage below normal, or shorted to low
source
94 110 3 Engine coolant temperatur sensor - Voltage above normal, or shorted to high
source
