OXE 200 HP - Page 66

60
MAINTENANCE
NIRA Internal
fault code
J1939
SPN
J1939
FMI
Description
160 DG_FNO_GEAR_ACTUATION_FAULT
161 DG_FNO_HB1_ELECTRICAL_FAULT
162 DG_FNO_HB2_ELECTRICAL_FAULT
163 DG_FNO_HB3_ELECTRICAL_FAULT
164 DG_FNO_HB4_ELECTRICAL_FAULT
165 Main relay - Electrical fault
95 110 4 Engine coolant temperatur sensor - Voltage below normal, or shorted to low
source
98 Engine oil temperature sensor - Voltage above normal, or shorted to high source
99 Engine oil temperature sensor - Voltage below normal, or shorted to low source
106 108 3 Ambient pressure sensor - Voltage above normal, or shorted to high source
107 108 4 Ambient pressure sensor - Voltage below normal, or shorted to low source
108 1136 ECU temperature sensor - Voltage above normal, or shorted to high source
109 1136 ECU temperature sensor - Voltage below normal, or shorted to low source
112 3509 3 ECU 5V sensor supply 1 - Voltage above normal, or shorted to high source
113 3509 4 ECU 5V sensor supply 1 - Voltage below normal, or shorted to low source
114 3510 3 ECU 5V sensor supply 2 - Voltage above normal, or shorted to high source
115 3510 4 ECU 5V sensor supply 2 - Voltage below normal, or shorted to low source
116 158 3 Battery potential - Voltage above normal
117 158 4 Battery potential - Voltage below normal
137 157 0 Fuel rail pressure - Data valid but above normal operational range
138 157 14 Fuel rail pressure - Control error
139 102 0 Manifold air pressure - Data valid but above normal operational range
140 102 14 Manifold air pressure - Control error
142 641 14 Turbo actuator -C ontrol error
