OXIGRAF O2iM - Appendix B - Terminal Board Diagrams

Oxigraf O2iM NEMA 4X Oxygen Analyzer
February 13, 2007 08-0427-B0, Manual, O2iM.doc Page 27
Key Function Display Line 1 Display Line 2
Show alarm relay status Alarm Relays... Horn/Strobe: Off
Alarm Relays... System OK: On
Alarm Relays... Warning: On
Alarm Relays... Alarm A: On
Alarm
Alarm Relays... Alarm B: Off
Back
Step back through alarms Alarm Relays... <previous msg>
Setup
Low O2 limit A Low O2 Alarm A 19.50% Oxygen
Setup
Continue with normal setup menu...
Help
Service help information
!#1. @:2:
O2iM version and serial number
$- <@?:(?2
Back
Go to previous state within submenu
<9);A%%"3%3%3"1"1#+
Appendix B – Terminal Board Diagrams
Terminal Board Rev A
