Oxigraf O2iM NEMA 4X Oxygen Analyzer
February 13, 2007 08-0427-B0, Manual, O2iM.doc Page 7
2.2 Options
The O2iM can be factory configured for specific applications. Some variations are:
• 5-Relay Terminal board. Each relay may be set up to close on high O2, low O2, or both.
Two additional relays indicate system OK status and sample flow/pressure status. The four
relays may also be assigned as individual channel alarms when the multipoint scan option is
installed.
• Four channel sequential multipoint gas sampler
• Internal battery backup system that will keep the O2iM operating and reporting (including
any of our remote indicators) for one hour if the external power is interrupted
• Remote indicator light module (wall mount for control rooms, etc)
• Hazardous area emote indicator light module
• Remote rackmount indicator light panel with digital display.
• Fixed XC, LN, or dual mode operation
• Hazardous area operation with Z-Purge for Class 1, Div 2 locations
Many of these can be installed in a single unit. Contact Oxigraf for details.
2.3 Accessories
The following accessories for the O2iM are available from Oxigraf:
• Low cal Gas (21.00% O
2
in nitrogen) “QD” 35 liter non-refillable cylinder Oxigraf part no.
2901-0020
• High cal Gas (99.99% O
2
in nitrogen) “QD” 35 liter non-refillable cylinder Oxigraf part no.
2901-0010
• Aluminum tubing kit
• Polyurethane tubing kit
2.4 Specifications
2.4.1 Performance Conditions
The performance specifications are valid under the following conditions:
Ambient temperature 5 to 40
o
C (40 to 105
o
F) operating; -20 to 60
o
C (-2 to 140
o
F) storage
Cell pressure 10.2 to 17.4 PSI (700 to 1200 mb) (500 to 900 mm Hg)
Warm-up for full accuracy 10 minutes
Altitude Two point calibration required after change in altitude of 2000 feet
Humidity 0 to 95%, non-condensing (at 40
o
C or lower
