SECTION 2 SPECIFICATIONS
Pacific Power Source ©2013 2-2 Document # 126050-10 Rev E
2.1.2 OUTPUT POWER
Power: 50 kW
Volt-Amps: 62.5 kVA
Voltage: 120/208 3Φ WYE. May be loaded WYE or DELTA.
0-132 VAC
L-N
Adjustment Range, with nominal input,
adjustable by front panel controls
Other voltages available as options..
Volt Regulation 0-100% Load Step: ±1% of output voltage regardless of load
unbalance, with AGC enabled.
Transient Voltage Regulation and Recovery: Output voltage recovers from a
50% load step to within 1% of nominal in less than 150
microseconds.
Harmonic Voltage Content for Linear Loads: Maximum 1% RMS total,
maximum 0.5% any single harmonic for linear loads 50-
60Hz, 2% RMS total for 400Hz. Paralleled Systems maybe
higher.
Current: 175 amps per phase.
Inverter Fault Clearing Current: Greater than 200% of full load.
Pulse Current: Greater than 200% per phase of pulse current for driving
non-linear loads.
Inverter Overload: - 150% of full load for 30 seconds
- 125% of full load for 10 minutes
- 110% of full load for 1 hour
Frequency Range Selectable, fixed frequencies at 50, 60, 400 Hz.
Variable frequency range 47-500 Hz.
External Oscillator input available.
Frequency Accuracy and Stability: ±0.01% typically for fixed frequencies.
Frequency Drift: ±0.01% for fixed frequencies. (24hr period)
Load Power Factor: No Restrictions
MODEL
NUMBER
Output
(KVA)
Output RMS
(KW)
Output
(CURRENT/Ø)
Output Short
Circuit
(CURRENT/Ø)
3060-MS
62.5
50
175A
>350A peak
FIGURE 2.1.3 OUTPUT RATINGS
For a paralleled cabinet system multiply the above ratings by the number of
cabinets in the system.
