Pacific Power Source MS SERIES - Figure 3.7.1 Output Contactor

SECTION 3 INSTALLATION
Pacific Power Source ©2013 3-17 Document # 126050-10 Rev E
FIGURE 3.7.1 OUTPUT CONTACTOR
(CUSTOMER LOAD WIRING DETAIL)
FIGURE 3.7.2 OPTIONAL OUTPUT CIRCUIT BREAKER
(CUSTOMER LOAD WIRING DETAIL)
PHASE A
PHASE B
PHASE C
OUTPUT SAFETY
GROUND / EARTH
SYSTEM NEUTRAL
CONNECTION
OUTPUT POWER
CONNECTION
