Pacific Power Source MS SERIES - Figure 3.7 Output Terminal Detail

SECTION 3 INSTALLATION
Pacific Power Source ©2013 3-16 Document # 126050-10 Rev E
NOTE
IT IS THE USER'S RESPONSIBILITY TO MEET ALL APPLICABLE LOCAL AND
NATIONAL CODE REQUIREMENTS WHEN INSTALLING THIS EQUIPMENT.
FIGURE 3.7 OUTPUT TERMINAL DETAIL
