SECTION 4 OPERATION
Pacific Power Source ©2013 4-6 Document # 126050-10 Rev E
4.3.1.1 INPUT KEY
The INPUT Key is used to display the current status of all power source input
power parameters. It may be pressed any time while power is applied to the unit.
I1 displayed when the INPUT key is pressed.
NORMAL input power is acceptable.
ABNORMAL input power is not acceptable.
FREQ input frequency.
V input volts, phase to neutral / phase to phase.
A input amps for each phase.
kW input kilowatts for each phase
kVA input kilo-Volt-Amps for each phase.
I1: INPUT V XXX/XXX XXX/XXX XXX/XXX
(AB)NORMAL A XXX XXX XXX
kW XX.X XX.X XX.X
FREQ=XXX.X kVA XX.X XX.X XX.X
4.3.1.2 OUTPUT KEY
The OUTPUT Key is used to display the current status of all power source output
power parameters. It may be pressed any time power is applied to the unit. Any
one of several OUTPUT displays can be seen by pressing OUTPUT and one of
the function keys (f1-f4) as follows:
O1 displayed when the OUTPUT then f1 keys are pressed, showing basic
output parameters for that cabinet.
V output volts, phase to neutral / phase to phase
A output amps for each phase.
EFF single cabinet operating efficiency
kW single cabinet output kilowatts for each phase
FREQ output frequency
kVA single cabinet output kilo-Volt-Amps for each phase.
O1: CABINET V XXX/XXX XXX/XXX XXX/XXX
OUTPUT A XXX XXX XXX
EFF=XX% kW XX.X XX.X XX.X
FREQ=XXX.X kVA XX.X XX.X XX.X
