SECTION 4 OPERATION
Pacific Power Source ©2013 4-7 Document # 126050-10 Rev E
O2 displayed when the OUTPUT then f2 keys are pressed, showing output
usage for that cabinet.
V output volts, phase to neutral / phase to phase
%I-PEAK percent of maximum peak amps for each phase.
%kVA percent of maximum kVA for each phase
FREQ output frequency
%kW percent of maximum kilowatts for each phase
O2: CABINET V XXX/XXX XXX/XXX XXX/XXX
OUTPUT %I-PEAK XXX XXX XXX
%kVA XXX XXX XXX
FREQ=XXX.X %kW XXX XXX XXX
O3 displayed when the OUTPUT then f3 keys are depressed, showing system
basic output parameters for multiple cabinet systems.
V output volts, phase to neutral / phase to phase
A total system output amps for each phase.
kW total system output kilowatts for each phase
FREQ output frequency
kVA total system output kilo-Volt-Amps for each phase.
O3: SYSTEM V XXX/XXX XXX/XXX XXX/XXX
SUMMARY A XXXX XXXX XXXX
OUTPUT kW XXX XXX XXX
FREQ=XXX.X kVA XXX XXX XXX
O4 displayed when the OUTPUT then f4 keys are depressed, showing remote
sense metering parameters.
V remote sense output volts, phase to neutral / phase to phase
A total system output amps for each phase.
kW total system output kilowatts for each phase
FREQ output frequency
kVA total system output kilo-Volt-Amps for each phase.
O4: REMOTE V XXX/XXX XXX/XXX XXX/XXX
OUTPUT A XXXX XXXX XXXX
KW XXX XXX XXX
FREQ=XXX.X kVA XXX XXX XXX
If any OUTPUT display is already active, it is not necessary to press the
OUTPUT key each time to view another message. Simply pressing another f1-f4
key will display the corresponding message.
