Pacific Power Source MS SERIES - Table 3.6.1 Installation Wiring

SECTION 3 INSTALLATION
Pacific Power Source ©2013 3-13 Document # 126050-10 Rev E
Each mainframe in an MS series system will draw the following load currents:
MODEL NUMBER 3060-MS
INPUT
VOLTAGE
FORM
100%
LOAD
RECOMMENDED
INPUT SVC.
MINIMUM INPUT WIRE
SIZE@75°C (167°F)
(COPPER CONDUCTOR)
AWG
mm
2
480
DELTA
75A
80A
3
35
380
DELTA
94A
100A
2
35
240
DELTA
150A
175A
1/0
70
208
DELTA
170A
175A
2/0
70
ALL
N/A
N/A
SAFETY GROUND /
EARTH
2/0
70
TABLE 3.6.1 INSTALLATION WIRING
FIGURE 3.6 INPUT TERMINAL DETAIL
