Pacific Power Source MS SERIES - DISPLAY PCB (126072 or 126172)

SECTION 4 OPERATION
Pacific Power Source ©2013 4-26 Document # 126050-10 Rev E
4.5.1 DISPLAY PCB (126072 or 126172)
Refer to figure 4.5.1, Display PCB. Two switches are located on this assembly.
Switch S42 is for testing and future use. Switch S41 provides the following
configuration information to the Power Source:
S41-1
S41-2
Machine Size
OFF
OFF
62.5kVA
OFF
ON
Undefined
ON
OFF
Undefined
ON
ON
Undefined
S41-3
Undefined
S41-4
Undefined
S41-5
S41-6
Serial Port "A" Baud Rate
OFF
OFF
300
OFF
ON
1200
ON
OFF
2400
ON
ON
9600
S41-7
S41-8
Serial Port "B" Baud Rate
OFF
OFF
300
OFF
ON
1200
ON
OFF
2400
ON
ON
9600
Normal Shipping Configuration is as follows:
S41-1
OFF
62.5kVA Machine
S41-2
OFF
62.5kVA Machine
S41-3
OFF
Undefined
S41-4
OFF
Undefined
S41-5
OFF
1200 Baud Serial Port A
S41-6
ON
1200 Baud Serial Port A
S41-7
OFF
1200 Baud Serial Port B
S41-8
ON
1200 Baud Serial Port B
S42-ALL
OFF
Undefined
