4.5.2 CONTROL PCB (126070 or 126079)
Refer to figure 4.5.2, Control PCB. One switch is located on this assembly.
Switch S14 provides for enabling of the auto restart option and local or remote
AGC (automatic gain control.)
Switch S14 assignments are as follows:
S14-1
Auto Restart
Normal
Configuration
as Shipped
OFF
OFF
OFF
ON
ON
S14-2
Undefined
OFF
S14-3
Phase A AGC
OFF
LOCAL
OFF
ON
REMOTE
S14-4
Phase B AGC
OFF
LOCAL
OFF
ON
REMOTE
S14-5
Phase C AGC
OFF
LOCAL
OFF
ON
REMOTE
S14-6
Phase A AGC
OFF
DISABLED
ON
ENABLED
ON
S14-7
Phase B AGC
OFF
DISABLED
ON
ENABLED
ON
S14-8
Phase C AGC
OFF
DISABLED
ON
ENABLED
ON
