SECTION 4 OPERATION
Pacific Power Source ©2013 4-30 Document # 126050-10 Rev E
4.6 FEATURE CONNECTORS
This paragraph describes the Feature Connectors contained within the MS-
Series AC Power Source, their purpose, location, and pin numbers. The use of
these connectors is optional. Refer to figure 4.6 for location of these connectors.
4.6.1 P1, P2 PARALLELING
These are used for Paralleling cabinets in multiple cabinet systems. They are
DB25P type. Pin numbers are as follows:
