S6 Displayed when the Power Source is in an Emergency Off state caused by
an OVERTEMP condition. The EMER OFF lamp shall be lit.
S6: CAB IS EMER OFF-WARNING-OVERTEMP
V XXX/XXX XXX/XXX XXX/XXX
A XXX XXX XXX
FREQ=XXX.X %LOAD XXX
S7 Displayed when the Power Source is in an Alarm condition caused by an
OUTPUT UNDER VOLTAGE.
S7: CAB IS ON - WARNING UNDER VOLTAGE
V XXX/XXX XXX/XXX XXX/XXX
A XXX XXX XXX
FREQ=XXX.X %LOAD XXX
S8 Displayed when the Power Source is in an Alarm condition caused by an
OUTPUT OVER VOLTAGE.
S8: CAB IS ON - WARNING OVER VOLTAGE
V XXX/XXX XXX/XXX XXX/XXX
A XXX XXX XXX
FREQ=XXX.X %LOAD XXX
S9 Displayed when the Power Source is in an Alarm condition caused by an
OUTPUT UNDER FREQUENCY.
S9: CAB IS ON - WARNING UNDER FREQUENCY
V XXX/XXX XXX/XXX XXX/XXX
A XXX XXX XXX
FREQ=XXX.X %LOAD XXX
S10 Displayed when the Power Source is in an Alarm condition caused by an
OUTPUT OVER FREQUENCY.
S10: CAB IS ON - WARNING OVER FREQUENCY
V XXX/XXX XXX/XXX XXX/XXX
A XXX XXX XXX
FREQ=XXX.X %LOAD XXX
