SECTION 4 OPERATION
Pacific Power Source ©2013 4-20 Document # 126050-10 Rev E
SLAVE STATE
SLAVE causes the machine to act as a slave in a multi cabinet system. The
machine is a SLAVE if the FREQUENCY SELECT switch is rotated to SLAVE,
and a MASTER if in any other position. The SLAVE lamp and either EMER OFF,
OFF, STANDBY or ON lamps shall be lit. The control mode shall be determined
by the following table:
MASTER
(Mode Switch
Position)
OFF
STANDBY
ON
SLAVE
(Mode
Switch
Position)
OFF
OFF
OFF
OFF
STANDBY
OFF
STANDBY
STANDBY
ON
OFF
STANDBY
ON
FIGURE 4.4.1 SLAVE CONTROL MODE
AUTO RE-START
If AUTO RE-START is enabled, the Power Source shall start AUTOMATICALLY
when input power is applied. The Power Source shall attain the mode as
selected by the MODE SELECT switch if all internal diagnostics check out ok.
WARNING
IF AUTO RE-START IS ENABLED, THE OUTPUT TERMINALS OF POWER SOURCE
MAY BE ENEGRIZED AUTOMATICALLY WHEN INPUT POWER IS APPLIED

