PACOM SmartIP-8SD - Status Setup Overview; Event Status Display

Part 3 - Conguration
69
Status Setup
Refer to the Menu Use on page 36 for basic information on using the Setup menus.
Event
This screen displays an overview of all events.
When an event occurs, the corresponding channel ashes for 5 seconds.
Event Types
Alarm-In Check Alarm-In Motion Video Loss
Audio Detection Trip Zone Tampering Text-In
t Panic Record: Displays event status based on current Panic Record status.
t Check Recording: Displays event status based on System Monitoring settings. For more information, refer to the
Monitoring on page 42.
t Disk Almost Full/Disk Full: If the storage device is not in Recycle status, event status is displayed when the amount
of disk space specied under System Monitoring is reached and when the disk becomes 100% full. For more
information, refer to the Monitoring on page 42.
t Fan Error: Event is indicated when the cooling fan cannot reach a certain RPM or fails for longer than 50 seconds.
t eSATA Disconnected: Event status is displayed when an eSATA device is abruptly disconnected.
t Disk Cong Change: It will be highlighted when the NVR reboots after the hard disk drive has been replaced.
t No Storage Found: It will be highlighted when no recordable storage device has been found.
