Palfinger Clocktower PK2400 TK - Rope Winch at Winding Device

104
Rope winch at winding device
Precondition: Winding device mounted
Unreeve the rope, loosen the bolt.
Disassemble the pulleys (rope guide).
Lift them main boom to c. 80°.
Extend the extension boom by one length.
Move the outer boom into transport position.
Reeve the rope in the winding device.
Remote control: Actuate slewing and then rope winch.
