Chapter 4 Device and function
Remote control console - main functions
1. Start switch
2. On LED lights up (red).
3. Speed button
4. Speed LED (green)
Radio connection status LED (red)
5. Emergency off / switch off
6. Motor start / stop button
1 - Start switch (start the remote control)
Prerequisites for starting:
Emergency off button is unlocked:
Operating voltage:
Key switch on crane is set to remote control;
Remote control transmitter battery is charged.
Starting:
The remote control transmitter is started by pressing the start button (1) once.
The operating status is indicated by the ‘On LED’ (2). ‘On LED’ illuminated in red; device is switched
on.
