Panasonic AFP7DA4H - Settings; Unit Setting and Conversion Processing Time

The set value will become effective when the set value is downloaded together with a
corresponding program as a project.
4.2.3 Settings
Group Setting item Settings Default
Basic setting
items
(per channel)
Output processing Execute / Not execute Execute
Range setting
-10 V to +10 V
0 V to +10 V
0 V to 5 V
+1 V to 5 V
0 V to 20 mA
4 mA to 20 mA
-10V to +10 V
Option setting
items
(per channel)
Upper and lower output clipping Execute / Not execute Not execute
Upper limit -32,500 to +32,500 0
Lower limit -32,500 to +32,500 0
Scale conversion Execute / Not execute Not execute
Max. value -30,000 to +30,000 10000
Min. value -30,000 to +30,000 0
Offset / Gain processing Execute / Not execute Not execute
Offset value -3,000 to +3,000 0
Gain value +9,000 to +11,000 10000
Analog output in PROG. mode
Non-hold / Current value hold /
Desired value hold
Non-hold
A digital value
corresponding to
the desired
analog output
-10 to +10 V
-32,500 to
+32,500
0
0 to +10 V
0 to 5 V
0 to 20 mA
0 to +32,500
+1 to 5 V
4 to 20 mA
0 to +25,000
4.2.4 Unit Setting and Conversion Processing Time
Conversion time varies with the configuration setting conditions.
■
Conversion processing execution / non-execution setting and conversion
processing time
Select the execution or non-execution of the conversion processing of analog output on a
channel-by-channel basis. This can save the conversion time for channels that do not execute
conversion processing. A conversion time of 25 μs is required per channel.
Example) Conversion time for four channels
