8.1 Specifications
■
General specifications
Items Description
Operating ambient
temperature
0°C to +55°C
Storage ambient
temperature
-40°C to +70°C
Operating ambient
humidity
10% to 95% (RH) with no condensation (at 25°C)
Storage ambient humidity 10% to 95% (RH) with no condensation (at 25°C)
Breakdown voltage
(Note 1)
Between I/O terminals
and power supply terminals of CPU unit / function earth
500 V AC for 1 minute
<Analog output unit>
Between analog output terminal channels
200 V AC for 1 minute
Insulation resistance Between I/O terminals
and power supply terminals of CPU unit / function earth
100 MΩ (Test voltage:
500 V DC)
Vibration resistance Conforming to JIS B 3502 and IEC 61131-2
5 to 8.4 Hz, 3.5-mm single amplitude
8.4 to 150 Hz, acceleration 9.8 m/s
2
10-time sweeping in X, Y, and Z directions (1 octave/min.)
Shock resistance Conforming to JIS B 3502 and IEC 61131-2
147 m/s
2
or more, 3 times each in X, Y, and Z directions
Noise resistance 1,000 V DC (p-p) with pulse width of 50 ns/1 μs
(by using a noise simulator) (Applied to the power supply of the CPU unit)
Environment Free from corrosive gases and excessive dust.
EU Directive applicable
standard
EMC Directive: EN 61131-2
Overvoltage category Category II
Pollution degree Pollution degree 2
(Note 1) Cutoff current: 5 mA (Factory default setting)
■
Performance specifications
Items Description
No. of output points 4 channels
Output range
(Resolution)
Voltage -10 to +10 V DC (Resolution: 1/62,500)
0 to +10 V DC (Resolution: 1/31,250)
0 to +5 V DC (Resolution: 1/31,250)
+1 to +5 V DC (Resolution: 1/25,000)
(Note 3)
Current 0 to +20 mA (Resolution: 1/31,250)
+4 to +20 mA (Resolution: 1/25,000)
(Note 3)
8.1 Specifications
8-2 WUME-FP7AOH-03
