Items Description
Conversion speed Voltage
input
25 μs/ch
Current
input
Total accuracy ±0.1% F.S. max. (at +25°C) and ±0.3% F.S. max. (at 0°C to +55°C)
Output impedance (voltage output) 0.5Ω max.
Maximum output current (voltage
output)
10 mA
Output allowable load resistance
(current output)
500 Ω max.
Insulation system Between input terminals and internal circuit: Photocoupler and isolated
DC/DC converter
Between channels: Non-isolated
Conversion execution / non-
execution channel settings
Possible to make non-converted channel settings.
Function of upper and lower output
clipping limits
Upper and lower output limits can be set for digital input values.
Setting range: -32,500 to +32,500
Scale conversion settings A desired value within the digital input range can be set.
Setting range: -30,000 to +30,000
Offset / gain settings A desired value within the digital input range can be set for the offset
value.
Setting range: -3,000 to +3,000
A desired value within the digital input range can be set for the gain value.
Setting range: +9,000 to +11,000 (90% to 110%)
Analog output hold
(while in PROG. mode)
A desired output value while in PROG. mode can be set as a digital value.
Setting range: -31,250 to +31,250
(Note 1) Set any of the following functions in the configuration menu of the tool software or a user program:
Output range, conversion execution / non-execution channel, upper and lower output clipping, scaling
processing, offset/gain, and (PROG. mode) analog output hold settings.
(Note 2) If not all channels are used, the conversion speed can be saved by setting non-execution channels
with the function of setting the conversion execution / non-execution channels used.
(Note 3) The full scale (F.S.) on the accuracy of an analog voltage output range from +1 to +5 V and that of an
analog current output range from +4 to +20 mA are 0 to +5 V and 0 to +20 mA, respectively.
8.1 Specifications
WUME-FP7AOH-03 8-3
