Unit memory
number
(Hex)
Name Default Setting range and description
H10: Current output 0 to +20 mA
H20: Current output +4 to +20 mA
UM 0010A
UM 0011A
UM 0012A
UM 0013A
Function setting
● Offset / Gain
processing
● Scale conversion
● Upper and lower
output clipping
● Analog output in
PROG. mode
H0
Select the function to be used.
bit Name Settings
3-0
Analog output
in PROG.
mode
H0: Non-hold (Output OFF)
H1: Current value held
H2: Desired value held
7-4
Offset / Gain
processing
H0: Not execute
H1: Execute
11-
8
Scale
conversion
H0: Not execute
H1: Execute
15-
10
Upper and
lower output
clipping
H0: Not execute
H1: Execute
(Note 1) The unit memory numbers in the above table are listed for CH0, CH1, CH2, and CH3 in numerical
order.
■
Individual setting area per channel
Unit memory
number
(Hex)
Name Default Setting range and description
UM 0010B
UM 0011B
UM 0012B
UM 0013B
Offset value K0
Set an offset value at the time of using the offset /
gain processing function.
Setting range: -3,000 to +3,000 (Specified with a
signed integer)
UM 0010C
UM 0011C
UM 0012C
UM 0013C
Gain value K10,000
Set an offset value at the time of using the offset /
gain processing function.
Setting range: +9,000 to +11,000 (0.9x to 1.1x:
Specified with a signed integer)
UM 0010D
UM 0011D
UM 0012D
UM 0013D
Scale conversion max.
value
K10,000
Set the maximum value at the time of using the
scale conversion function.
Setting range: -30,000 to +30,000 (Specified with a
signed integer)
UM 0010E
UM 0011E
UM 0012E
UM 0013E
Scale conversion min.
value
K0
Set the minimum value at the time of using the scale
conversion function.
Setting range: -30,000 to +30,000 (Specified with a
signed integer)
UM 0010F
UM 0011F
UM 0012F
UM 0013F
Upper limit for upper and
lower output clipping
K0
Set the upper limit to turn ON the upper limit relay
for the use of the function of clipping upper and
lower output.
Setting range: -32,500 to +32,500 (Specified with a
signed integer)
8.3 List of Unit Memory
8-6 WUME-FP7AOH-03
