90
BB-HCM511A/BB-HCM531A
14.3.2.2. BB-HCM531A
14.3.3. CPU Board Parts
14.3.3.1. BB-HCM511A
Ref.
No.
Part No. Part Name & Description Rema
rks
A101 PQKL10082Z1 FLEXIBLE STAND S
A102 PQME10080Z ANGLE, SAFETY WIRE
A103 XTB4+20AFJ TAPPING SCREW
A104 XTN26+10GVW TAPPING SCREW
A105 XWG26D12VW WASHER
A106 XWG4F16VW WASHER
A107 PQQX15704YCD INSTRUCTION BOOK (CD-ROM) S
A108 PQQW15579Z LEAFLET
A109 PQQX15757Z INSTRUCTION BOOK,
Setup Guide
A110 PQQX15758Z INSTRUCTION BOOK, Instal-
lation Guide
A111 PQQX15756Z LEAFLE T
A112 PQYCHCM531A COVER
A113 PSHG1235Z TAP E
A114 PQKV10074Z1 COVER S
P101 PQPK15687Z GIFT BOX
P102 PQPN11794Z ACCESSORY BOX
P103 PQPD10786Z CUSHION
P104 PQPH10097Z P A C KI N G S H E E T
P105 XZB20X30A05 P R O T E C T I O N C O V E R
P106 PQPD10859Z CUSHION
P107 PQPD10865Z CUSHION
P108 PSPD1302Z CUSHION
P109 PSPN1177Z ACCESSORY BOX
P110 PQPN11797Z ACCESSORY BOX
P111 XZB23X34A05 P R O T E C T I O N C O V E R
Safe
ty
Ref.
No.
Part No. Part Name & Description Rema
rks
PCB1 PQWP1HCM511A CPU BOARD ASS'Y (RTL)
(ICs)
IC101 C0EBE0000231 IC
IC102 MN103SC30EYD IC
IC103 C3ABQG000070 IC
IC104 There is no parts supply of only IC104 please
order PCB1 (PQWP1HCM511A).
IC105 C1CB00002568 IC
IC106 C3ABQG000070 IC
IC107 C0BBBA000044 IC
IC108 C0GBF0000020 IC
IC109 C1AB00002139 IC
IC110 C1ZBZ0003497 IC
IC114 C0DBAFZ00054 IC
IC116 RPI-352 IC S
IC117 C0DBGYY00198 IC
(TRANSISTORS)
Q101 2SA1576R T R A N S I S T O R ( S I ) S
Q102 PQVTDTC143E T R A N S I S T O R ( S I ) S
Q103 PQVTDTC143E T R A N S I S T O R ( S I ) S
Q106 PQVTDTC143E T R A N S I S T O R ( S I ) S
Q107 PQVTDTC143E T R A N S I S T O R ( S I ) S
IC111 B1DHCD000018 T R A N S I S T O R ( S I )
(DIODES)
D101 MA741WK D I O DE(SI ) S
D102 MA736 DIODE(SI) S
D103 MA3082 DIODE(SI) S
LED101 B3ABB0000291 D I O DE(SI )
(CONNECTORS)
CN102 K1MN27BA0184 CONNECTOR, 27 Pin
CN103 K1MY04AA0057 CONNECTOR, 4 Pin
CN104 K1MN18BA0160 CONNECTOR, 18 Pin
CN105 K1NA14E00002 CONNECTOR, 14 Pin
CN106 K1MN32BA0153 CONNECTOR, 32 Pin
(COILS AND CERAMIC FIL-
TERS)
L101 G1C1R0JA0041 COIL
L102 G1C1R0JA0041 COIL
L103 G1C1R0JA0041 COIL
L108 G1C4R7MA0098 COIL
L112 J0JBC0000071 C E R A M I C F IL T E R
L114 J0JBC0000071 C E R A M I C F IL T E R
L115 J0JBC0000071 C E R A M I C F IL T E R
L116 G1C1R0JA0041 COIL
L118 J0JBC0000071 C E R A M I C F IL T E R
L119 G1C1R0JA0041 COIL
L120 J0JBC0000071 C E R A M I C F IL T E R
L121 G1A220GA0005 COIL
L124 G1C100M00027 COIL
L126 PQLQR1RS241 COIL S
L127 G1C100M00027 COIL
R141 J0JCC0000315 C E R A M I C F IL T E R
R146 PQLQR1RM601 COIL S
R147 PQLQR1RM601 COIL S
R148 PQLQR1RM601 COIL S
R149 PQLQR1RM601 COIL S
R152 J0JCC0000315 C E R A M I C F IL T E R
R153 J0JCC0000315 C E R A M I C F IL T E R
R154 J0JCC0000315 C E R A M I C F IL T E R
R155 J0JCC0000315 C E R A M I C F IL T E R
R156 J0JCC0000315 C E R A M I C F IL T E R
R157 J0JCC0000315 C E R A M I C F IL T E R
R158 J0JCC0000315 C E R A M I C F IL T E R
R159 J0JCC0000315 C E R A M I C F IL T E R
R160 J0JCC0000315 C E R A M I C F IL T E R
R161 J0JCC0000315 C E R A M I C F IL T E R
R162 J0JCC0000315 C E R A M I C F IL T E R
R163 J0JCC0000315 C E R A M I C F IL T E R
R164 J0JCC0000315 C E R A M I C F IL T E R
R187 J0JCC0000315 C E R A M I C F IL T E R
R188 J0JCC0000315 C E R A M I C F IL T E R
R190 J0JCC0000315 C E R A M I C F IL T E R
R191 J0JCC0000315 C E R A M I C F IL T E R
R192 J0JCC0000315 C E R A M I C F IL T E R
R193 J0JCC0000315 C E R A M I C F IL T E R
R194 J0JCC0000315 C E R A M I C F IL T E R
R226 J0JCC0000250 C E R A M I C F IL T E R
R228 J0JCC0000315 C E R A M I C F IL T E R
R229 J0JCC0000315 C E R A M I C F IL T E R
R230 J0JCC0000315 C E R A M I C F IL T E R
R231 J0JCC0000315 C E R A M I C F IL T E R
R232 J0JCC0000315 C E R A M I C F IL T E R
R233 PQLQR1RM601 COIL S
R234 PQLQR1RM601 COIL S
R235 PQLQR1RM601 COIL S
R236 PQLQR1RM601 COIL S
R237 PQLQR1RM601 COIL S
R238 PQLQR1RM601 COIL S
R244 J0JCC0000250 C E R A M I C F IL T E R
R245 J0JCC0000250 C E R A M I C F IL T E R
R261 J0JCC0000315 C E R A M I C F IL T E R
R269 J0JCC0000250 C E R A M I C F IL T E R
(COMPONENTS PARTS)
RA101 D1H84724A024 RESISTOR ARRAY
RA105 D1H84704A024 RESISTOR ARRAY
RA107 D1H84704A024 RESISTOR ARRAY
(IC FILTERS)
L128 J0JBC0000107 I C FILTER
RA102 J0JAD0000007 I C FIL T E R
Safe
ty
Ref.
No.
Part No. Part Name & Description Rema
rks
To Next Page
