Panasonic BB-HCM511A - Page 96

96
BB-HCM511A/BB-HCM531A
14.3.5. PoE Board Parts
R515 ERJ3GEYJ105 1M
R516 ERJ3GEYJ332 3.3k
R517 ERJ3GEYJ332 3.3k
R518 ERJ3GEYJ203 20k
R519 ERJ3GEYJ203 20k
R520 ERJ3GEYJ103 10k
R521 ERJ3GEYJ103 10k
R522 ERJ3GEYJ152 1.5k
R523 ERJ3GEYJ222 2.2k
R524 ERJ3GEYJ561 560
R525 ERJ3GEYJ103 10k
R526 ERJ3GEYJ103 10k
R527 ERJ3GEYJ103 10k
R528 ERJ3GEYJ101 100
R529 ERJ3GEYJ154 150k
R530 ERJ3GEYJ680 68
R531 ERJ3GEYJ820 82
R532 ERJ3GEYJ561 560
(CAPACITORS)
C501 ECJ1VF1C104Z 0.1
C502 ECJ1VC1H121J 120p
C503 ECST0JX476 47 S
C504 PQCUV1A105KB 1 S
C505 ECJ1VF1E104Z 0.1
C506 F1J0J1060006 10
C507 ECUV1A224KBV 0.22 S
C508 ECJ1VF1E104Z 0.1
C509 ECUV0J105KBV 1 S
C510 ECUV0J105KBV 1 S
C511 ECUV0J105KBV 1 S
C513 ECUV0J105KBV 1 S
C514 ECUE1H100DCQ 10p
C515 ECUV0J105KBV 1 S
C516 ECJ1VC1H331J 330p
C517 ECUE1H100DCQ 10p
C518 ECUE1H100DCQ 10p
C519 F1J0J1060006 10
C520 F1J0J1060006 10
C521 ECJ1VF1C104Z 0.1
C522 ECJ1VF1C104Z 0.1
C523 ECJ1VB1C474K 0.47
C524 ECJ1VB1H122K 0.0012
C525 ECJ1VB1H122K 0.0012
C526 ECUV0J105KBV 1 S
C527 ECUV0J105KBV 1 S
C528 ECUV1H100JCV 10p
C529 ECJ1VF1C104Z 0.1
C530 ECJ1VF1C104Z 0.1
C531 ECJ1VC1H121J 120p
C532 ECJ1VF1E104Z 0.1
C533 ECST0JX476 47 S
C534 PQCUV1A105KB 1 S
C535 ECJ1VB1C473K 0.047
C536 ECJ1VB1C473K 0.047
C537 ECJ1VF1C104Z 0.1
C538 ECJ1VF1C104Z 0.1
C539 ECJ1VF1C104Z 0.1
C540 ECJ1VF1C104Z 0.1
C541 ECJ1VB1H102K 0.001
C542 F1J0J1060006 10
C544 ECJ1VC1H331J 330p
C545 ECJ1VB1C474K 0.47
C546 F1J0J1060006 10
C547 ECJ1VF1C104Z 0.1
C548 ECJ1VF1E104Z 0.1
C549 F1J0J1060006 10
C550 ECJ1VF1C104Z 0.1
C551 F2B1C1020005 1000
C552 ECJ1VC1H121J 120p
Safe
ty
Ref.
No.
Part No. Part Name & Description Rema
rks
Safe
ty
Ref.
No.
Part No. Part Name & Description Rema
rks
PCB3 PQWP3HCM515A POE BOARD ASS'Y (RTL)
(ICs)
IC601 C1CB00002237 IC
IC603 C0DBBZC00002 IC
(TRANSISTORS)
Q601 B1ABBL000006 TRANSISTOR(SI)
Q602 B1CFND000007 TRANSISTOR(SI)
IC602 B1CFMM000001 TRANSISTOR(SI)
(DIODES)
D601 B0JCML000005 DIODE(SI)
D602 B0JCML000005 DIODE(SI)
D603 B0JCML000005 DIODE(SI)
D604 B0JCML000005 DIODE(SI)
D605 B0JCML000005 DIODE(SI)
D606 B0JCML000005 DIODE(SI)
D607 B0JCML000005 DIODE(SI)
D608 B0JCML000005 DIODE(SI)
D609 B0BC06700001 DIODE(SI)
D610 B0BC8R100004 DIODE(SI)
D611 B0BC01000014 DIODE(SI)
D613 B0BC06700001 DIODE(SI)
D614 B0BC06700001 DIODE(SI)
D615 B0HCMM000017 DIODE(SI)
D616 B0JCCL000004 DIODE(SI)
D617 B0HCMM000017 DIODE(SI)
D618 B0JCPG000015 DIODE(SI)
D619 B0JCPG000015 DIODE(SI)
D620 B0BC01600022 DIODE(SI)
D621 MA736 DIODE(SI) S
D622 B0BC01000014 DIODE(SI)
(CONNECTOR AND JACK)
CN601 K2LC108B0046 JACK
CN602 K1MN18BA0134 CONNECTOR,18 Pin
(COILS, IC FILTER AND
CERAMIC FILTERS)
L601 J0MAB0000185 I C FILTER
L602 J0MAB0000185 I C FILTER
L603 G1C3R3MA0072 COIL
L605 G1C6R8Z00005 COIL
L606 PQVFCM04RC01 C E R A M I C F IL T E R S
FLT601 G0B150G00001 COIL
FLT602 G0B150G00001 COIL
R604 J0JBC0000082 I C FILTER
R607 J0JBC0000082 I C FILTER
R625 PQLQR1RM121 COIL S
R627 PQLQR1RM121 COIL S
R628 PQLQR1RS102 COIL S
R629 PQLQR1RM121 COIL S
R630 PQLQR1RS102 COIL S
R633 J0JCC0000315 COIL
(VARISTORS)
SA601 D4ZZ00000024 VARISTOR(Surge Absorber)
SA602 D4ZZ00000024 VARISTOR(Surge Absorber)
SA603 D4ZZ00000024 VARISTOR(Surge Absorber)
SA604 D4ZZ00000024 VARISTOR(Surge Absorber)
(TRANSFORMERS)
T601 G5BZC0000014 TRANSFORMER
L604 G5DYB0000013 TRANSFORMER
(PHOTO ELECTRIC TRANS-
DUCER)
PC601 B3PBA0000297 PHOTO COUPLER
